Barcode Scanners
Imager 2D Barcode Scanner Reader BS110
Are you looking for a barcode reader that offers speed, precision and resistance? Then the Pos & Office BS110 model is what you need. This 2D Imager reader allows you to scan 1D and 2D barcodes, even if they are damaged or deteriorated, by simply holding them close to the device. The BS110 has an automatic…
Description
-
Are you looking for a barcode reader that offers speed, precision and resistance? Then the Pos & Office BS110 model is what you need.
-
This 2D Imager reader allows you to scan 1D and 2D barcodes, even if they are damaged or deteriorated, by simply holding them close to the device.
-
The BS110 has an automatic reading option on the stand, so you don’t have to press any button.
-
The BS110 scanner has a robust design that resists drops of up to 2 meters, and an IP52 rating that protects it from dust and water.
-
The BS110 barcode reader has an audible signal and a blue LED indicator that indicates the status of the reading carried out.
-
The BS110 is ideal for collection networks, supermarkets, convenience stores, pharmacies, gas stations, retail and small businesses, as it helps speed up the payment process and avoid errors.
Technical specifications
Technical specifications
- Dimensions
- 158mm x 55mm x 93mm
- Weight
- 220 grams (with cable)
What is in the box
1x BS110 scanner (includes USB cable)
1x Quick user guide
1x Quick user guide
Image sensor
640px x 480px
Resolution
≥ 5 thousand
Light level
0 – 100,000 Lux
Light source
617nm LEDs
Illumination: 4500K LEDs
Depth of field
40-200mm @ UPC/EAN 13 thousand PCS =90%
20-250mm @ QR 20mil PCS =100%
Minimum print contrast
25%
Scan angle
65°, 30°, 55°
640px x 480px
Resolution
≥ 5 thousand
Light level
0 – 100,000 Lux
Light source
617nm LEDs
Illumination: 4500K LEDs
Depth of field
40-200mm @ UPC/EAN 13 thousand PCS =90%
20-250mm @ QR 20mil PCS =100%
Minimum print contrast
25%
Scan angle
65°, 30°, 55°
Operating temperature
-20 to 60°C
Storage temperature
-40 to 70°C
Humidity
5% to 95% (non-condensing)
Protection against dust and water ingress
IP52
Drop resistance
Resists 2 meter drops onto concrete
-20 to 60°C
Storage temperature
-40 to 70°C
Humidity
5% to 95% (non-condensing)
Protection against dust and water ingress
IP52
Drop resistance
Resists 2 meter drops onto concrete
DATA CAPTURE
1D
All major symbologies including UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128, Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, IATA Code, MSI/Plessey, Code 32, RSS 14, RSS Limited, RSS Expanded
2D
All major symbologies including QR Code, Data Matrix, PDF417, Aztec, Maxicode, GS1 DataBar stack
All major symbologies including UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128, Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, IATA Code, MSI/Plessey, Code 32, RSS 14, RSS Limited, RSS Expanded
2D
All major symbologies including QR Code, Data Matrix, PDF417, Aztec, Maxicode, GS1 DataBar stack
PHYSICAL CHARACTERISTICS
Dimensions
158mm x 55mm x 93mm
Weight
220 grams (with cable)
Interfaces
USB
Cable length
1.8 meters
Notifications
Beep, blue LED indicator
Input voltage
5 VDC ± 10%
Running current
170mA (typical)
Optional
Stand for automatic reading on base
158mm x 55mm x 93mm
Weight
220 grams (with cable)
Interfaces
USB
Cable length
1.8 meters
Notifications
Beep, blue LED indicator
Input voltage
5 VDC ± 10%
Running current
170mA (typical)
Optional
Stand for automatic reading on base
