Imager 2D Barcode Reader Wireless with Cradle BS140

Imager 2D Barcode Reader Wireless with Cradle BS140

  • It is increasingly common to find 2D barcodes on different types of products. In order to read them, a barcode reader capable of reading 2-dimensional codes is required.
  • Introducing the BS140 barcode reader, optimized for reading 1D as well as 2D barcodes. Most linear and 2D barcodes are easily read by the BS140, even those with wear and tear.
  • Thanks to its wireless technology, the BS140 can be connected via Bluetooth or Wireless 2.4Ghz, giving users freedom of use.
  • Specially designed for supermarkets, convenience stores, retail, gastronomy, pharmacies, service stations, logistics operations and many other businesses.

Dimensions

173mm x 66mm x 94mm

Weight

202grs

Box contents

1x BS140 scanner (includes base, USB cable and stand)

View full details

Technical specifications

  • PERFORMANCE

    Reader type
    2D Imager
    Resolution
    640x480
    Reading method
    Manual, Automatic
    Light source
    625nm LED sight
    4000K LED lighting
    Reading angle
    Lateral 55°, Rotation 360°, Vertical 55°
    Contrast
    ≥20%
    Precision
    ≥4 thousand
    Depth of field
    20-200mm @EAN 13 thousand PCS=100%
    5-170mm @ QR 20mil PCS=100%
    Frames per second
    30fps/s
    Ambient light
    0~100000Lux
    Field of view
    45° Horizontal, 34° Vertical
    Memory capacity
    380000 bytes
    Wireless communication distance
    2.4GHZ: 100 meters
    Bluetooth HID: 40 meters (in open sky)

  • ENVIRONMENTAL

    Operating temperature
    -20° to 60°C
    Storage temperature
    -40° to 70°C
    Humidity
    5% to 95% (non-condensing)
    Resistance to dust and water entry
    IP52
    Drop resistance
    Resists 2 meter drops onto concrete

  • DATA CAPTURE

    It can read barcodes from screens.
    1D
    All major symbologies including UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar ( NW7), Code 128 & EAN 128, Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, IATA Code, MSI/Plessey, China Postal Code, Code 32 (Italian Pharmacode), RSS-14, RSS-Limited , RSS-Expanded, etc.
    2D
    All major symbologies including QR Code, PDF417, Data Matrix, Aztec, Maxicode, Dotcode, GS1 DataBar Stacked, etc.

  • PHYSICAL CHARACTERISTICS

    Dimensions
    Scanner: 173mm x 66mm x 94mm
    Base: 122mm x 75mm x 94mm
    Weight
    Scanner: 202grs
    Base: 132grs
    Cable length
    1.5 meters
    Notifications
    Red, Blue and Green LED Light
    Beep and vibration
    Material
    ABS+PC, TPU

  • ENERGY

    Input voltage
    5VDC ±5%
    Running current
    400mA (typical)
    Battery
    2000mAh
    Charging mode
    Wireless based
    Loading time
    5 hours
    Battery life
    12 hours (with continuous reading)
