Discover the TD80 Thermal Label Printer from Pos & Office: Precision and Speed for your Business
The Pos & Office TD80 thermal label and paper printer is the ideal tool to optimize your labeling operations. Designed to offer precision, speed and versatility, this printer is perfect for shops, warehouses, and businesses looking for efficient solutions for label management.
Exceptional print quality
Thanks to its 203 dpi resolution, the TD80 ensures crisp, high-quality labels, with a print speed of up to 152mm per second. With a maximum print width of 108mm, this printer can handle a wide range of label sizes and styles, from product identifiers to barcodes and logistics labels.
Support for multiple paper formats
The TD80 direct thermal printer supports thermal paper rolls and thermal labels with a width of up to 127mm. Its design includes a paper sensor to ensure accurate and uninterrupted performance.
Modern interfaces and optional connectivity
This printer features a standard USB interface and LAN, Bluetooth and Wi-Fi connectivity options to suit the needs of your work environment.
Guaranteed durability
Built to last, it features a print head with a 50km print lifespan. Its robust design and high-quality materials ensure reliable performance in demanding conditions.
Compatible with multiple operating systems
The TD80 is compatible with Windows, Linux, Mac, and features an SDK for integration into Android and iOS systems. It supports TSPL and EPL emulations, making it easy to use with different types of labeling software and applications.
TD80 by Pos & Office: Simplify and accelerate your labeling processes with the quality and reliability that your business deserves.
Dimensions
Dimensions
197mm x 116mm x 105mm
Weight
Weight
1.15Kgs
Box contents
Box contents
1x TD80 Printer
1x Power supply
1x USB Cable
1x Quick User Guide
1x Roll of labels (sample)
1x Label holder
Technical specifications
-
PRINTING PARAMETERS
Printing method
Direct Thermal
Resolution
203dpi
Print width
108mm
Print speed
152mm/sec
Print source
Source A: 12x24
Source B: 9x17
Source C: 24x24
Printhead life
50km -
PAPER
Type of paper
Thermal paper roll, thermal label roll
Paper width
127mm
Thickness
0.06~0.25 mm
Roll diameter
76mm maximum
Cutting method
Manual
Paper feed direction
Upward -
GENERAL CHARACTERISTICS
Processor
32-bit CPU
Memory
8MB Flash/8MB SDRAM
Interfaces
USB
LAN (optional)
Bluetooth (optional)
Wi-Fi (optional)
Indicators
Error
Sensors
Paper sensor
Lid opening sensor
Keys
1x On/Off
1x Feed
Barcodes
1D
Code 39, Code 93, Code 128UCC, Code 128 ,subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN & UPC 2(5) additional digits, MSI, PLESSEY, POSTNET, China POST
2D
PDF-417, Maxicode, DataMatrix, QR code
Energy
Input: AC 110~240V 50-60Hz
Output: DC 24V, 2.5A -
SOFTWARE
Emulation
TSPL, EPL
Drivers
Windows/Linux/Mac
SDK
Android/iOS -
PHYSICAL CHARACTERISTICS
Dimensions
197mm x 116mm x 105mm
Weight
1.15kgs
Color
Black and White / White and Blue / White and Red
Operating temperature
5~40°C - Humidity: 25~85% non-condensing
Storage temperature
-40~60°C – Humidity: 10~90% non-condensing -
-
